SNS系列水泥振動篩
水泥振動篩結構獨特新穎，打破傳統設計方案，振動力由振動源直接帶動篩網，從而使整機減輕重量約1/3，節約動力1/2，是所有振動篩中較先進的產品。水泥振動篩體積小，效率高、噪音低，運轉平穩，維修方便，篩孔為5*5，經久耐用。
Cement vibrating screen has structure unique, breaking the traditional design scheme of power driven directly by the vibration source of vibration sieve, thus make the whole machine weight about 1/3, 1/2, saving power is more advanced vibrating screen of all products.Cement vibrating screen is small in size, high efficiency, low noise, stable running, convenient maintenance, the mesh is 5 * 5, durable.
Vibrating screen is for cement, lime and cement designed similar powder material screening machinery;The operation is simple, compact structure, less wearing parts, easy maintenance;The new energy-saving vibration motor as vibration source, there are mainly two single vibrating motor and vibration motor structure;Cement screen machine is mainly used for cement clinker classifying and finished products, screen mesh for weaving nets;Vibration damping device installation, generally for a type, damping spring has two kinds of steel spring and rubber spring.
水泥振動篩結構特點
1、該機結構先進、體積小、重量輕、效率高、噪聲低、運轉平穩、采用振動電機直接驅動篩網進行篩分工作；
2、采用優質高錳鋼編織網，經久耐磨且更換維修方便，篩網一般為4*4mm或者5*5mm；還可以根據客戶要求定做；
3、比回轉篩節電效益顯著，篩分效率超高。
Features
1, the machine of advanced structure, small volume, light weight, high efficiency, low noise, smooth operation, the vibration motor direct drive mesh sieve;
2, high quality, high manganese steel weaving nets, durability and convenient replacement and maintenance, screen mesh is commonly 4 * 4 mm or 5 * 5 mm;Can also be customized according to customer requirements;
3,saving electricity benefit is remarkable, high screening efficiency.
水泥振動篩主要應用范圍及用途
水泥振動篩結構合理，獨特新穎，采用振動電機做激振源，物料進行拋擲運動，達到篩分處理的目的，改掉了滾筒篩和連桿往復篩的堵篩，粘網，換網難的缺點，該機廣泛用于篩除水泥，石灰及類似的粉狀物料的異物，以保證輸送設備和包裝設備的安全運轉。 該機結構先進，體積小，重量輕，效率高，噪音低，采用新型的振動電機作直接驅動。 篩網結構簡單，維修方便，篩網采用高強度金屬編織網，經久耐用。 該機座式或吊掛式均可。
Applications
Cement vibrating screen structure is reasonable, unique and novel, the vibration motor excitation source, materials are getting throwing motion, to achieve the purpose of the screening process, get rid of the drum sieve and link of reciprocating sieve, twigs, difficult to replace the network faults, the machine is widely used in screen in addition to cement, lime powder materials and similar foreign bodies, to ensure the safe operation of conveyor equipment and packaging equipment.With advanced structure, small volume, light weight, high efficiency, low noise, the new type of vibration motor for direct drive.Screen mesh is simple structure, convenient maintenance, high strength metal weaving nets, durable.This machine is a type or hanging.
水泥振動篩主要技術參數表
Parameters| 型號及參數 | 處理量（t/h） | 篩孔尺寸mm | 篩面傾角 | 振動頻率（次/分） | 電機功率（KW） |
| SNS-30 | 30 | 5×5 | 7° | 960 | 0.75 |
| SNS-60 | 60 | 5×5 | 7° | 960 | 0.75 |
| SNS-90 | 90 | 5×5 | 7° | 960 | 1.50 |
| SNS-120 | 120 | 5×5 | 7° | 960 | 1.50 |
| SNS-200 | 200 | 5×5 | 7° | 960 | 1.50 |
水泥振動篩安裝說明
振動電機底腳螺栓孔與底腳螺栓的配合應緊密。底腳螺栓要牢固可靠，需用止逆螺母或彈簧墊圈等鎖緊，以防止松動。1、激振力調整：
每臺電機兩端偏心塊同方向轉動，使活動偏心塊所需要激振力刻度線對正軸頭線。
2、 操作使用：
兩臺電機必須同步反方向運轉，否則調換相序。
電機累計運行100小時內，每隔24小時，對固件（螺栓）重新緊固一次，運行100小時止，應最
后增強緊固一遍。經常打開觀察口，觀察和清除篩上的殘留異物。
Installation and Guidance
Vibration motor foot bolt hole and cooperate with the foot bolt should be close.Bottom bolt to solid and reliable, need check inverse nut or spring washer and so on lock, in order to prevent the loose.
1, the excitation adjustment:
Each motor turn eccentric block on both ends of the same direction, make activity eccentric block vibration force needed lines to scale to align the shaft head.
2, operation:
Two motors must synchronous running in the opposite direction, or change the phase sequence.
Motor running 100 hours, every 24 hours, the firmware (bolt) retightened time, running 100 hours, should be the most enhanced after fastening it again.Often open mouth observation, observation and clear the residual matter on the screen.
