振動篩篩板

篩板是篩分設備重要的核心部件，振動篩振動時，物料通過不同幾何形狀不同尺寸大小的篩板，在外力的作用下，將不同粒度的物料進行分離，達到分級目的。
物料的各種特性，篩板的不同結構，材質及篩機的各種參數都對振動篩的篩分能力、效率、跑粗率及壽命產生一定的影響，不同的物料，不同的場所應選用不同的篩板，以達到篩分的最佳效果。
梳齒篩板：
梳齒篩板是我公司自行開發的應用廣泛的主導篩板產品，該篩板具有不堵塞、篩分效率高的顯著特點，適用于煤炭、冶金、化工等行業燒結、熟料、焦碳以及各種生塊礦石等硬度較高、重量較大的干物料，該篩板根據選用材質不同，可以達到不同的使用壽命。
根據材質不同可分為：噴涂篩板、高耐磨合金篩板、新型耐磨合金鋼篩板、普通篩板、堆焊篩板。
物料的分級粒度3-25mm、25-80mm。
Screen plate is an important core parts of screening equipment, vibrating screen, vibration materials with different geometry size of the screen plate, under the action of external force, the materials of different granularity separation, the purpose of classification.
Properties of materials, different structure of the screen plate, all sorts of material and sieve machine parameters of vibrating screen screening ability, efficiency, run a sketchy and life have influence, different materials, different places should choose different sieve plate, screening in order to achieve the best effect.
Comb screen plate:
Comb screen plate is my company developed leading screen plate products, widely used in the screen plate is not blocked, significant characteristics of high screening efficiency, applicable to coal, metallurgy, chemical industry such as sintering, clinker, coke as well as a variety of raw ore such as high hardness, weight, larger dry material, the sieve plate according to choose material is qualitative different, can achieve different life.
According to different materials can be divided into: sieve plate coating, high wear resistance alloy sieve plate, new wear resistant alloy steel sieve plate, the common screen plate, welding screen plate.
Material grading granularity of 3 to 25 mm, 25-80 - mm.

棒條篩板：
棒條篩板是我公司跟蹤國際先進技術，研制開發的新型結構篩板。
該篩板的高頻音叉條，在隨篩板振動的同時，產生二次高頻諧振，使物料前進速度加快，加速了篩面上顆粒物料的下沉和已接觸篩面的小顆粒物料向篩孔處橫移的速度，從而增加了通過篩孔的概率，該篩板的開孔最高可達80%，有一定水分的粘物，靠其高頻自振抖落，不易粘結在篩條造成堵塞，是粘性或含有纖維物的難篩物料最為理想的篩板。
適用范圍：原煤的分級、燒結、球團、焦炭、礦石等。
物料的分級粒度：5-40mm。
Bars sieve plate:
Bars screen plate is my company tracking the international advanced technology, research and development of a new type of  plate structure.
The screen plate of high frequency tuning fork, while with sieve plate vibration, produce secondary high frequency resonance, make the material move faster, accelerated the sinking of sieve particles on the surface of the material and small particles have touch screen surface materials to mesh transverse speed, thereby increasing the probability of through the screen mesh, opening up to 80% of the sieve plate, have certain moisture sticky material, by the high frequency vibration shake, bonding caused jams in bar is not easily, is sticky or difficult to screen material containing fiber content, the ideal sieve plate.
Scope of application: raw coal classification, sinter, pellets, coke, ore, etc.
Material grading granularity: 5-40 mm.



鑄造篩板：
鑄造篩板分熱篩鑄造篩板、冷鑄造篩板
該篩板似乎具有耐磨、耐腐蝕、抗沖擊的高強度篩板，主要用于燒結、焦炭、礦石等原料的篩分作業。
熱鑄造篩板：生產種類有各種規格形狀的不銹鋼鑄造篩板，其篩孔形狀常為人字孔。
冷鑄造篩板：生產種類有各種規格形狀的不銹鋼鑄造篩板、高強度耐磨鑄造篩板、普通鑄鋼篩板、高鉻鑄鋼篩板、球鐵篩板等。其篩孔形狀有長方孔、方孔、菱形孔、梳齒孔、人字孔和錐形孔等。

Casting screen plate:
It points hot casting screen plate, cold casting screen plate
The screen plate seems to has high wear resistance, corrosion resistance, resistance to impact strength sieve plate, it is mainly used for sintering, coke, ore screen raw materials such as homework.
Hot casting sieve plate: there are all kinds of species production stainless steel screen plate, in the shape of the mesh hole shape is often a word.
Cold casting screen plate: there are all kinds of stainless steel screen plate in the shape of species production, high strength wear resistant casting sieve plate, the common cast steel sieve plate of ductile iron, high chromium cast steel sieve plate, screen plate, etc.The mesh shape of rectangular hole, square hole, diamond hole, the comb tooth holes, herringbone hole and cone hole, etc.
